Amplificator Mixer cu 5 intrari audio Yamaha PCA 60 USB

Commercial audio amplifier & 5 input mixer.
Solid state audio player/recorder (USB/SD) with standard formats (MP3, WMA).
Supports storage devices of up to 32 GB.
2 Aux inputs.
3 Mic inputs.
Mic 1 input with priority.
Mixer with independent control of volume,
Master control and treble/bass tone.
Pre-out function.
Suitable for low impedance speakers (8 Ω) and high impedance loads (25/70/100 V).
Chime On/Off switch.
Telephone/Emergency connection for paging and emergency announcements.
Terminals for emergency supply (24 V dc).
2U rack enclosure.

Caracteristici:

Audio inputs:    3 Mic, 2 Aux. level.
Mic (impedance/sensitivity):    250 Ω / 1 mV bal.
Aux (impedance/sensitivity):    47 kΩ / 200 mV.
Tape output:    4.7 kΩ / 350 mV.
Pre-out :    600 Ω / 1 V.
Outputs:    8 Ω / 25 V / 70 V / 100 V.
Output power:    60 W.
Frequency response:    50 Hz - 20 kHz +/- 3 dB.
EQ controls:
- Bass
- Treble    +/- 10 dB. / 31 Hz -180 Hz / C. freq. 68 Hz
+/- 10 dB / 2.5 kHz - 20 kHz / C. freq. 10 kHz
S/N ratio :    75 dB (Line) / 60 dB (Mic).
Main supply :    AC 115/230 V, 50/60 Hz / DC 24 V-8A.
Consumption :    170 W.
Dimensions :    483 x 88 x 260 mm (WxHxD).
Weight:    8 kg.
